| Model specification |
WPF6 |
WPF8 |
|
| Platform height |
mm |
6000 |
8000 |
| Machine height |
mm |
7100 |
9100 |
| Minimum platform height |
mm |
1080 |
1200 |
| Distance from base to ground |
mm |
20 |
20 |
| Platform load rating |
kg |
300 |
300 |
| Platform extension load |
kg |
100 |
100 |
| Working platform size |
mm |
1880x900 |
|
| Working platform size |
mm |
900 |
|
| Maximum driving speed (platform lowered) |
km/h |
3~4 |
|
| Maximum driving speed (platform raised) |
km/h |
0.6~1 |
|
| Minimum turning radius |
mm |
2000 |
|
| Maximum climbing ability |
% |
10~15 |
|
| Drive wheel size |
mm |
Φ305x100 |
|
| Directional wheel size |
in |
Φ305x100 |
|
| motor |
v/kw |
2x24/0.5 |
|
| Lifting motor |
v/kw |
24/2.2 |
|
| Battery |
v/Ah |
2x12/150 |
|
| charger |
v/A |
24V/25 |
|
| Pothole protection system |
Mechanical control |
||
| Length of the whole machine |
mm |
2050 |
|
| Overall width |
mm |
900 |
|
| Overall height (folding railing) |
mm |
1735 |
1860 |
| Total Weight |
kg |
1500 |
1700 |
